HDMI Video: Supports FHD and Up to 3840×2160@60Hz
Built-in Safety: ESD Protection for Reliable Operation
Transmission Limit: 150m (Cat6a+), 120m (Cat5e) over STP
8ms @ 60fps
8ms @ 60fps
~900Mbit/s
~900Mbit/s
| Specifications | KFH236S_TX | KFH236S_RX | |
| Connections | DisplayPort input | 2 | N/A |
| DisplayPort output | 2 | 2 | |
| Power | 2x 12V | 2x 12V | |
| LAN port | 2x RJ45 | 2x RJ45 | |
| Optical Module | 2x SFP | 2x SFP | |
| Mic | 3.5mm Stereo Jack (Pink) x1 | 3.5mm Stereo Jack (Pink) x1 | |
| Speaker | 3.5mm Stereo Jack (Green) x1 | 3.5mm Stereo Jack (Green) x1 | |
| USB Type B | 1 | N/A | |
| USB Type A | N/A | 4 | |
| Resolution | 3840×2160@60Hz | ||
| Cable | Fiber optical or CAT5e/6/7 cable | ||
| I/R Value | DC12V / 3A | DC12V / 3A | |
| Power consumption | 19W | 22W | |
| Operating temperature | 0—50 ℃ | ||
| Storage temperature | -20—60 ℃ | ||
| Humidity | 0—80% RH, non-condensing | ||
| Material | Metal | ||
| Net weight(kg) | 1.03 kg | 1.03kg | |
| Product dimension (W × D × H) | 210mm x 132.2 mm x 44mm | ||
| Package dimension (W × D × H) | 395mmx 274mm x 110mm | 395mmx 274mm x 110mm | |
