Single Rail 17″ 16 Port USB VGA LCD KVM Switch

Model No.: XL1716

Simple Design: Integrated KVM Console with 19″ LCD monitor.
Control of Computers: A single console controls up to 8 computers.
High Video Resolution: The resolution is up to 1280 x 1024 @60Hz.
Diverse Computer Switching Options: Front panel LEDs, keyboard hotkey combination or on-screen-display (OSD) menu.
Daisy-chain Connection: Support daisy-chain connection and control up to 512 computers.
Hot Plugging: Easy to add or remove servers and no need to power off the LCD KVM switch.

Get A Free Quote

Features

Diagram

Specification

Accessory

Download

Overview

The Kinan’s XL1716 LCD KVM Switch features an integrated 17″ LCD screen, keyboard and touchpad in a single console that occupies only 1U of rack space. It allows access and control up to 16 computers from a single console (keyboard, mouse and monitor). The number of connected computers can be increased up to 512 by daisy-chaining up to 31 XM0108 KVM Switches.

The XL1716 KVM Console has a built-in LCD monitor that supports resolution up to 1280×1024@60Hz. Switching between computers can be easily accomplished by front panel pushbuttons, keyboard hotkey combination or on-screen-display (OSD).

The LCD KVM switch supports USB connection for the computers. An extra HDB15 port allows an additional VGA monitor to be connected.

Hardware Features

Integrated KVM Console with 17” LCD monitor, keyboard/touchpad and 16 port KVM switch in a 1U height console
Standard VGA connection-Connect to a server or computer via standard VGA connectors
LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
Support computers with USB and PS/2 keyboard and mouse

Hardware Features

Integrated KVM Console with 17” LCD monitor, keyboard/touchpad and 16 port KVM switch in a 1U height console
Standard VGA connection-Connect to a server or computer via standard VGA connectors
LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
Support computers with USB and PS/2 keyboard and mouse

Management

Convenient computer switching via front panel LEDs, keyboard hotkey combination or on-screen-display (OSD)
Auto scan feature for monitoring user-selected computer
Broadcast mode–operations simultaneously performed on all selected computers
Hot pluggable –add or remove computers without having to power down the switch
Quickly select your computer by naming the server or inputting SN number of the server
On-Screen Display (OSD) adjustments-Adjust the on-screen image, including: auto adjust, exit, power on/off, brightness, and menu

Management

Convenient computer switching via front panel LEDs, keyboard hotkey combination or on-screen-display (OSD)
Auto scan feature for monitoring user-selected computer
Broadcast mode–operations simultaneously performed on all selected computers
Hot pluggable –add or remove computers without having to power down the switch
Quickly select your computer by naming the server or inputting SN number of the server
On-Screen Display (OSD) adjustments-Adjust the on-screen image, including: auto adjust, exit, power on/off, brightness, and menu

High Resolution

17″ TFT LCD KVM monitor with highlight, high definition and high resolution
Optimum resolution is up to 1280 x 1024 @60Hz, max resolution supports up to 1280×1024@75Hz

High Resolution

17″ TFT LCD KVM monitor with highlight, high definition and high resolution
Optimum resolution is up to 1280 x 1024 @60Hz, max resolution supports up to 1280×1024@75Hz

Daisy-Chain Connection

By daisy-chaining up to another 31 switches, as many as 512 servers can be controlled from a single console

Daisy-Chain Connection

By daisy-chaining up to another 31 switches, as many as 512 servers can be controlled from a single console

Security

Two level password security–only authorized users view and control computers
Supports one administrator and four user accounts with a separate profile for each

Security

Two level password security–only authorized users view and control computers
Supports one administrator and four user accounts with a separate profile for each

High Performance Touchpad

Touchpad with scroll wheel – Eliminates the need for a separate, external mouse

High Performance Touchpad

Touchpad with scroll wheel – Eliminates the need for a separate, external mouse

Keyboard

Multi-language support–English, Russian, German, French, UK and Spanish, etc.
Full size 99 keys keyboard with integrated number pad

Keyboard

Multi-language support–English, Russian, German, French, UK and Spanish, etc.
Full size 99 keys keyboard with integrated number pad

Wide Compatibility

Multiplatform Support-Compatible with Windows, Sun, Unix and Linux
Supports servers form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.

Wide Compatibility

Multiplatform Support-Compatible with Windows, Sun, Unix and Linux
Supports servers form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.

Diagram

Specification

Model		XL1716
Computer connections	Direct	16
Computer connections	Max	512
Port emulation	Keyboard, mouse	USB
LED monitor	LED model	SXGA TFT
	View area	17″
	Optimum resolution	1280×1024@60Hz
	Display color	16.7 M
	Brightness	250cd/m²（ T y p ）
	Contrast ratio	1000 : 1 （ T y p ）
	Pixel pitch(mm)	0.264(H) × 0.264(W)
Mouse	X/Y resolution	>1000 points /inch, (40 points/mm)
Mouse	Roll wheel	Supports scroll wheel function
Keyboard		99 keys (82 keys main keyboard +17 independent small numeric keyboard)
Port selection		Front panel pushbuttons, hotkeys, OSD menu
Input power		100V- 240Vac, 50-60Hz, <1.5A
Power consumption		19W
Mounting distance		600~850mm (L=420mm) Mounting rails can be customized for other mounting distance.
Operating temperature		0—50 ℃
Store temperature		-20—60 ℃
Humidity		0—80% RH, non-condensing
Net weight		13 kg
Product dimension (W × D × H)		448mm×581mm×42.5mm
Package dimension (W × D × H)		765mm×615mm×185mm
Optional power input		-36V— -72V DC
