Reliable & Protected: Dual power supply redundancy and built-in ESD protection.
High-Quality, Low-Latency Video: Uses proprietary lossless compression for visually lossless video. Supports 1x DVI channel up to 1920×1200@60Hz with ultra-low latency of 1 frame (e.g., 16ms @ 60fps).
High-Speed, Multi-Interface Connectivity: Offers a typical bandwidth of 200-300 Mbps. Interfaces include Gigabit Ethernet, Fiber (SFP/FC), 1x asynchronous serial port, and USB 2.0 for connecting up to 4 peripherals.
Flexible Long-Distance Operation: Supports point-to-point connection over Gigabit switches. Enables direct cable runs of up to 150 meters.
Audio Support: Features an analog microphone audio input.
| Specification | KFD262S_TX | KFD262S_RX | |||
| Connection | DVI Input | 2 | NA | ||
| DVI Output | NA | 2 | |||
| Power | DC12V x 2 | DC12V x 2 | |||
| LAN Port | RJ45 x 2 | RJ45 x 2 | |||
| SFP Port | SFP x 2 | SFP x 2 | |||
| Microphone | 3.5mm Stereo Jack(Pink) | 3.5mm Stereo Jack(Pink) | |||
| Speaker | 3.5mm Stereo Jack(Green) | 3.5mm Stereo Jack(Green) | |||
| IR Interface | 3.5mm Stereo Jack(Black) | 3.5mm Stereo Jack(Black) | |||
| Square USB | 1 | N/A | |||
| USB | N/A | 4 | |||
| Max Resolution | 1920*1200@60HZ | ||||
| Connected Cables | Optical fibre (type dependent on optical module) | ||||
| Power Input | DC12V / 2A | DC12V / 2A | |||
| Power Consumption | 7W | 9W | |||
| Operating Temperature | 0–50 ℃ | ||||
| Storage Temperature | -20–60 ℃ | ||||
| Humidity | 0–80% RH, non-condensing | ||||
| Net Weight (kg) | 0.95kg | 0.95kg | |||
| Material | Metal | ||||
| Product Dimension (W × D × H) | 189×144×44mm | 189×144×44mm | |||
