1-Local / 2-Remote Access 8 Port Cat5 KVM over IP Switch

Model No.: HT1208

  • High video resolution – resolution is up to 1920×1080@60Hz for local and remote console
  • Rack-mountable in 1U system rack
  • Dual power supply
  • Support 1 local user and 2 remote user, port share mode allows local and remote users to gain access to a server simultaneously
  • Support servers with VGA/DVI/HDMI/DP port
  • Configurable user and group permissions for server access and control

Overview

The HT1208 1-Local/2-Remote Access Cat5 8 port KVM over IP Switch is an ideal solution for your IT systems, no software needed, no complicated installation procedures, and no compatibility issues.

The HT1208 uses TCP/IP communications protocol, it can be accessed by its IP address through IE browser or a windows-based client from anywhere on the LAN, WAN or Internet. The KVM Switch allows 1 local user and 2 remote users to monitor and access 8 servers from a single console. Connect servers with Cat 5e/6 cable, it supports servers with VGA, DVI, HDMI, and DP port. The 8 port KVM over IP switch can be installed in a 1U rack.

The HT1208 allows for centralized management on the computer/server from anywhere, a Windows client is available for remote access. In addition, Kinan also offers an IP receiver for remote access to the HT1208 directly, it supports freely switching between local and remote computer, no need for remote access to the device via the web-based browser.

Hardware Features

  • Rack-mountable in 1U system rack
  • Standard Cat5 connection-Connect to a server or computer via standard RJ-45 connectors and Cat5e/6 cables
  • External console port – provides an external VGA, keyboard and mouse port to manage the IP KVM Switch from an external console
  • One bus for IP KVM remote access
  • Dual power supply

Hardware Features

  • Rack-mountable in 1U system rack
  • Standard Cat5 connection-Connect to a server or computer via standard RJ-45 connectors and Cat5e/6 cables
  • External console port – provides an external VGA, keyboard and mouse port to manage the IP KVM Switch from an external console
  • One bus for IP KVM remote access
  • Dual power supply

Local Console

  • Controls up to 8 computers from a single console
  • Support 1 local user and 2 remote users, port share mode allows local and remote users to gain access to a server simultaneously
  • Easy-to-use switching by browser-based UI interface, hotkeys and pushbuttons
  • Support servers with VGA/DVI/HDMI/DP port
  • Multiplatform client support – Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
  • Local Console, Browser, and AP GUIs offer a unified management interface
  • Local resolution is up to 1920×1080@60Hz
  • Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
  • Video synchronization with local console – EDID information for local console display can be stored in the host module for video resolution optimization
  • Keyboard and mouse emulation to ensure the normal booting
  • Auto scan feature for monitoring user-selected computer
  • Hot pluggable–add or remove computers without having to power down the switch

Local Console

  • Controls up to 8 computers from a single console
  • Support 1 local user and 2 remote users, port share mode allows local and remote users to gain access to a server simultaneously
  • Easy-to-use switching by browser-based UI interface, hotkeys and pushbuttons
  • Support servers with VGA/DVI/HDMI/DP port
  • Multiplatform client support – Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
  • Local Console, Browser, and AP GUIs offer a unified management interface
  • Local resolution is up to 1920×1080@60Hz
  • Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
  • Video synchronization with local console – EDID information for local console display can be stored in the host module for video resolution optimization
  • Keyboard and mouse emulation to ensure the normal booting
  • Auto scan feature for monitoring user-selected computer
  • Hot pluggable–add or remove computers without having to power down the switch

Remote Console

  • Adaptive 10 / 100 / 1000 Mbps network
  • WEB browser-based remote management
  • Resolution for remote console is up to 1920×1080@60Hz
  • BIOS-level access
  • Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 30 FPS
  • Full screen or scalable video display
  • Remote users and local users can control the same server/computer synchronously
  • Support AES / DES / 3DES encryption
  • Support audit function-allows the administrator to audit the device through the system log and operation log
  • Exit Macros support
  • Configurable user and group permissions for server access and control
  • Support strong password
  • Support firmware upgrade

Remote Console

  • Adaptive 10 / 100 / 1000 Mbps network
  • WEB browser-based remote management
  • Resolution for remote console is up to 1920×1080@60Hz
  • BIOS-level access
  • Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 30 FPS
  • Full screen or scalable video display
  • Remote users and local users can control the same server/computer synchronously
  • Support AES / DES / 3DES encryption
  • Support audit function-allows the administrator to audit the device through the system log and operation log
  • Exit Macros support
  • Configurable user and group permissions for server access and control
  • Support strong password
  • Support firmware upgrade

Diagram

Connection Diagram HT1208-1

Specification

Model HT1208
Computer Connection 8
Port selection 8
Port selection Pushbutton, UI, Web, Hotkey
Connector Console Keyboard 2x USB TYPE A
Mouse
Monitor 1-HDB-15 Female(blue)
KVM Port (RJ-45) 8
Upgrading switch 1x RJ11 Female
Power 3-Prong AC socket
Switch Port Selection 8
Reset 1x touch-button
Upgrading switch 1x toggle switch
Power 1x rocker switch
LEDs Online (Green) 8
Selected (Orange) 8
Power 1(blue)
Cascade display 2x 7- Segment (orange)
Remote control KVM control (ActiveX control)
Remote Management way Web
Security DES encryption
Resolution 1920×1080@60Hz
I/R Value 100V-240Vac, 50-60Hz, <1.5A
Power Consumption 17W
Environment Requirements Operating Temperature 0 — 50 ℃
Store Temperature -20— 60 ℃
Humidity 0—80%RH, Non-condensing
Physical Features Material Metal
Weight 3kg
Dimension 433x171x44.5mm

Package Contents

  • 1x HT1208 KVM over IP Switch
  • 1x Power Cord (Regional)
  • 1x Quick Start Guide
  • 1x User Manual
  • 2x Mounting Rails
  • 1x Cat5 shield network cable
  • 1x Ground Lead
